2-Color Flexo Printing Machine
2-Color Flexo Printing Machine, also called aniline press which uses photosensitive resin plate as the printing plate of printing machine. It adopts environmental ink and has advantage of low edition-producing cost, this is an ideal machine for mass lots, large variety production manufacturer. It is also suitable for printing HDPE, LDPE, PP, cellophane paper, rolling paper etc. 2-Color Flexo Printing Machine is your best choice.
Uh oh!
Something is wrong with your Wufoo shortcode. If you copy and paste it from the Wufoo Code Manager, you should be golden.
Model YT-2600
| Model | YT-2600 |
| Max. Material Width | 600mm |
| Max. Printing Width | 560mm |
| Length Range Of Printing | 191~914mm |
| Accuracy Of Registration | ±0.5mm |
| Max. Diameter Of material Roll | Φ450mm |
| Output Capacity | 5~50m/min |
| Thickness Of Plate (including two-sides glue paper) | 2.38mm |
| Total Power | 8kw |
| Weight | 1800kg |
| Overall Dimension(L x W x H) | 2500 x 1700 x 2200mm |
Model YT-2800
| Model | YT-2800 |
| Max. Material Width | 800mm |
| Max. Printing Width | 760mm |
| Length Range Of Printing | 191~914mm |
| Accuracy Of Registration | ±0.5mm |
| Max. Diameter Of material Roll | Φ450mm |
| Output Capacity | 5~50m/min |
| Thickness Of Plate (including two-sides glue paper) | 2.38mm |
| Total Power | 10kw |
| Weight | 2000kg |
| Overall Dimension(L x W x H) | 2500 x 1900 x 2200 mm |
Model YT-21000
| Model | YT-21000 |
| Max. Material Width | 1000mm |
| Max. Printing Width | 960mm |
| Length Range Of Printing | 191~914mm |
| Accuracy Of Registration | ±0.5mm |
| Max. Diameter Of material Roll | Φ450mm |
| Output Capacity | 5~50m/min |
| Thickness Of Plate (including two-sides glue paper) | 2.38mm |
| Total Power | 12kw |
| Weight | 2100kg |
| Overall Dimension(L x W x H) | 2500 x 1900 x 2200 mm |
Model YT-21200
| Model | YT-21200 |
| Max. Material Width | 1200mm |
| Max. Printing Width | 1160mm |
| Length Range Of Printing | 191~914mm |
| Accuracy Of Registration | ±0.5mm |
| Max. Diameter Of material Roll | Φ450mm |
| Output Capacity | 5~50m/min |
| Thickness Of Plate (including two-sides glue paper) | 2.38mm |
| Total Power | 14kw |
| Weight | 2400kg |
| Overall Dimension(L x W x H) | 2500 x 2300 x 2200 mm |
