PE Air Bubble Film Extruding Machine

PE Air Bubble Film Extruding Machine

PE Air Bubble Film Extruding Machine is designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.It is optimum designed on the rounds of preference of analogous lines in foreign and home. The lines can be blown continuous 800/1500mm in fold width, 0.08mm.In the thickness packaging films, film has good insulation, for instance holding temperature, anti-humid, anti-breeze, anti-rain, anti-rost, insulation oxygen oil resistive, and so used for light and heavy-duty packaging, for example fresh fruits, meat-feeding, salt vegetables, fresh milk, drink. PE Air Bubble Film Extruding Machine is your best choice.

Video Request for this machine, please Contact Us Now!

Fill out my online form.

Model QPE-1000
Main And Auxiliary Extruder Screw Diameter Φ60mm
L/D Ratio 28:1
Main And Auxiliary Extruder Electrical Power 30kw
Width Of Production 1000mm
Main Bubble Specification 25 x 10mm 10 x 3.6mm 30 x 10mm
Output 60kg/h
Total Installed Capacity 50kw
Weight 6T
Overall Dimension 7500 x 3300 x 2500 mm
Model QPE-1200
Main And Auxiliary Extruder Screw Diameter Φ50mm
L/D Ratio 28:1
Main And Auxiliary Extruder Electrical Power 30kw
Width Of Production 1200mm
Main Bubble Specification 25 x 10mm 10 x 3.6mm 30 x 10mm
Output 70kg/h
Total Installed Capacity 50kw
Weight 6T
Overall Dimension 7500 x 3300 x 2500 mm
Model QPE-1500
Main And Auxiliary Extruder Screw Diameter Φ75mm
L/D Ratio 28:1
Main And Auxiliary Extruder Electrical Power 30kw
Width Of Production 1500mm
Main Bubble Specification 25 x 10mm 10 x 3.6mm 30 x 10mm
Output 90kg/h
Total Installed Capacity 50kw
Weight 6T
Overall Dimension 7500 x 3300 x 2500 mm
Model QPE-1800
Main And Auxiliary Extruder Screw Diameter Φ90mm
L/D Ratio 1.167361111
Main And Auxiliary Extruder Electrical Power 30kw
Width Of Production 1800mm
Main Bubble Specification 25 x 10mm 10 x 3.6mm 30 x 10mm
Output 86kg/h
Total Installed Capacity 50kw
Weight 6T
Overall Dimension 7500 x 3300 x 2500 mm
Model QPE-2000
Main And Auxiliary Extruder Screw Diameter Φ95mm
L/D Ratio 28:1
Main And Auxiliary Extruder Electrical Power 30kw
Width Of Production 2000mm
Main Bubble Specification 25 x 10mm 10 x 3.6mm 30 x 10mm
Output 95kg/h
Total Installed Capacity 50kw
Weight 6T
Overall Dimension 7500 x 3300 x 2500 mm
